NANO

OMNIUM NANO – SRAM APEX

Built for the City. Ready for Anything.

The Omnium Nano is a compact cargo bike built for real urban life. Tight spaces, apartment living, transit integration, quick errands, big hauls — it handles all of it without feeling like a compromise.

With its smaller footprint and 20” wheels, the Nano delivers a fast, agile ride while still offering serious carrying capability. It’s the kind of bike that replaces car trips without feeling like you’re riding a tank.

Why the Nano Works

• Compact footprint
  Easy to store, park, and maneuver in tight city environments
• Agile ride feel
  Shorter wheelbase + 20” wheels = quick acceleration and responsive handling
• Multimodal ready
  Works seamlessly with public transit for longer urban commutes
• Cargo capable
  Front rack handles up to 50kg, with a total system weight of 125kg
• Expandable platform
  Compatible with Omnium Cargo & Mini-Max V3 accessories, including Tilting Rack Bracket for even smaller storage footprint

Design

Designed around dual 20” wheels (55-406), the Nano is built for stop-and-go city riding. Smaller wheels spin up faster, making it ideal for traffic lights, tight turns, and urban flow.

A sloped top tube lowers standover height, making this a true one-size bike that fits riders from 160cm to 190cm comfortably.

Despite its size, it keeps the DNA of Omnium’s larger cargo bikes — stable under load, predictable handling, and surprisingly natural to ride.

Drivetrain & Brakes

The SRAM Apex 11-speed setup keeps things simple, durable, and reliable.

• Drivetrain: SRAM Apex 1x11
• Cassette: SRAM Force 11–36
• Chainring: 42T
• Brakes: SRAM Level TL hydraulic disc
• Chain: KMC

Paired with 20” wheels, this gearing delivers a lower effective range, making climbs and loaded riding feel easier without sacrificing speed on flats.

Cockpit & Finishing Kit

Comes dialed with Omnium’s standard cockpit — solid, comfortable, and ready to ride.

You can fully customize in the Bike Builder if you want to tweak fit or style.

• Handlebar: Omnium Riser Bar
• Stem: Omnium LW Stem
• Grips: Lock-on Foam
• Saddle: Omnium Standard
• Seatpost: 31.6mm Forged
• Pedals: Omnium Cargo

Wheels & Tires

• Front Wheel: 20” (406), 15x100mm thru axle
• Rear Wheel: 20” (406), 12x142mm thru axle
• Rims: 38mm outer width
• Tires: Schwalbe Big Ben 55-406

Wide, stable, and comfortable — perfect for mixed urban terrain.

Frame & Specs

• Frame: Double-butted chromoly steel
• Fork: 15x100mm thru axle
• Bottom Bracket: 68mm BSA
• Headset: 1 1/8”
• Rack Size: 400 x 500mm
• Max Front Load: 50kg
• Max System Weight: 125kg
• Complete Weight: 16.5kg

The Feel

This is what makes the Nano special — it doesn’t ride like a cargo bike.

It feels quick, balanced, and intuitive. You hop on, and within minutes it just makes sense.

Run errands, haul gear, hit the market, commute across the city — it handles all of it without slowing you down.
