Surly Skid Loader - Illegal Smile Green

The Skid Loader is Surly's compact electric cargo bike: longtail utility with a footprint that fits anywhere a normal bike does. Bosch Performance Line Cargo motor with up to 85Nm of torque, dual-battery capable for extended range, and a dedicated rear rack rated for 100 lb of whatever you need to haul.

Engineered to ride and feel like a regular bike — 27.5" wheels, abundant tire clearance, and dropper post across all three sizes. Internal cable routing for shifter, brake, lights, and dropper keeps everything clean.

Why Skid Loader

• Bosch Performance Line Cargo (Smart System) with Purion 200 Remote — 4 levels of assist
• Dual-battery capable for extended range
• 100 lb-rated rear rack with M6 hardware
• 27.5" wheels with 2.5" ExtraTerrestrial tires
• Internal routing for dropper, brake, shifter, and lights
• Stable dual-leg kickstand (Ursus Jumbo 80) and front-wheel stabilizer for easy loading
• Integrated AXA Nxt 60 headlight + AXA Blueline taillight
• UL 2849 and UL 2271 certified
• Class 1 e-bike, max assist speed 20 mph

Frameset

• Frame: 100% Surly Chromoly Steel, Natch tubing, double-butted, TIG welded, ED coated
• Fork: 100% Surly Chromoly Steel, Natch tubing, double-butted tapered blades
• Color: Illegal Smile Green
• Sizes: Small, Medium, Large

E-system

• Motor: Bosch Performance Line Cargo, 85Nm torque, 400% max assist
• Battery: Bosch PowerPack 545 (545Wh, 36V, 14.4Ah) — removable, dual-battery capable
• Charger: Bosch 4A charger included (~1.8 hr to 50%, ~4.9 hr to 100%)
• Range: 15-50 miles depending on assist mode, load, and conditions
• Display: Purion 200 Remote

Drivetrain

• Rear derailleur: Shimano CUES U6000 GS
• Shifter: Shimano CUES U6000
• Cassette: Shimano Linkglide LG300, 11-48t, 10-speed
• Chain: Shimano Linkglide LG500
• Crankset: FSA CK-763, 38t

Brakes

• Levers & calipers: Tektro HD-M750, 4-piston hydraulic disc
• Rotors: Tektro 180/180, 6-bolt

Wheels & tires

• Rims: WTB HTZ Trail i35 27.5", TCS 2.0
• Front hub: Novatec 15 x 110mm, 6-bolt, 36h
• Rear hub: Novatec 12 x 148mm, 6-bolt, 36h
• Tires: Surly ExtraTerrestrial 27.5 x 2.5", 60 tpi, tubeless-ready

Cockpit & finishing kit

• Handlebar: Surly Terminal
• Stem: Kalloy 31.8
• Grips: Velo Black
• Saddle: WTB Volt Medium
• Seatpost: Tranz-X YSP15 dropper, 120mm travel
• Headset: Cane Creek Viscoset upper / 40 Series lower
• Rear rack: Surly Skid Loader dedicated, 100 lb-rated

Capacity

• Gross payload: 400 lb max (rider + cargo)
• Rack: 100 lb (deck alone: 59 lb / 27 kg)
• Complete bike weight: 60 lb 15 oz (Medium)

Specifications subject to change without notice.
